Hikvision DS-7104HQHI-K1 4-ch 1080p Mini 1U H.265 DVR


In stock

4 channels and 1 HDD mini-size DVR

Efficient H.265 pro+ compression technology

5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)

Up to 6 network cameras can be connected

Brand: Hikvision
Model: DS-7104HQHI-K1
Offer Price: 5600
Warranty: 1 Year
Status: In Stock
Contact No: 01999-088831, 01999-088832, 01999-088834


Hikvision DS-7104HQHI-K1 is a 4-channel 1080p Mini 1U H.265 DVR. It is a small and affordable DVR that is ideal for small businesses and homes. It features H.265 pro+ compression technology, which can save up to 90% of storage space compared to H.264. It also supports 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP), so you can connect a variety of different types of cameras to it.

Specification Hikvision DS-7104HQHI-K1

Video Compression H.265 Pro+/ H.265 Pro/ H.265/ H.264+/ H.264
Encoding Resolution 1080p Lite mode is not enabled:
4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled:
4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame Rate Main stream:
When 1080p Lite mode is not enabled:
For 4 MP stream access:
4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
For 1080p stream access:
1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode is enabled:
4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
Video Bit Rate 32 Kbps to 6 Mbps
Audio Bit Rate 64 kbps
Dual Stream Support
Audio Compression G.711u
Stream Type Video, Video and Audio
Video And Audio
IP Video Input 1-ch (up to 5-ch)
Enhanced IP mode on:
2-ch (up to 6-ch), each up to 4 Mbps
Up to 6mp resolution Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input 4 channel BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Turbo HD Input
AHD Input
4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS Input Support
Audio Input 1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output 1-ch, RCA (Linear, 1 KΩ)
2-way Audio Reuse the 1st audio input
Synchronous Playback 4-ch
VGA/HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Auxiliary Interface
SATA 1 SATA interface
Capacity Up to 6 TB capacity for each disk
USB Interface Rear panel: 2 × USB 2.0
Alarm In/Out N/A
Total Bandwidth 72 Mbps
Remote Connections 32
Network Protocols TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network Interface 1, RJ45 10M/100M self-adaptive Ethernet interface
Dimensions (W×D×H) 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
Weights ≤ 1 kg (2.2 lb) (Without HDD)
Power Supply 12 VDC, 1.5 A
Consumption ≤ 8 W (Without HDD)
Warranty 1(one) year warranty

Hikvision DS-7104HQHI-K1 4-ch 1080p Mini 1U H.265 DVR

The Hikvision DS-7104HQHI-K1 is a top-of-the-line 4-channel DVR designed to meet the needs of small-scale surveillance systems. With its compact 1U form factor, the DVR offers a space-saving solution while delivering high-quality video performance. The device supports 1080p resolution video and utilizes H.265 video compression technology, ensuring that you get clear and detailed images with improved compression efficiency. The advanced features, such as cloud connectivity and intelligent video analysis, allow you to monitor your premises remotely, giving you peace of mind even when you’re away. The device’s user-friendly interface and robust security features ensure that your surveillance system is both easy to use and secure. If you’re looking for a reliable, cost-effective, and high-performance DVR, the Hikvision DS-7104HQHI-K1 is an excellent choice.

What is the price of Hikvision DS-7104HQHI-K1 4-ch 1080p Mini 1U H.265 DVR Price in BD?

This Hikvision DS-7104HQHI-K1 with 4-ch 1080p Mini 1U H.265 DVR at the Latest Price of only 5600 tk from us, Up to 6 network cameras can be connected, and you can get it at the best price from us in BD. Also, get a warranty and offers on eligible orders. Contact us at 01999088831-34

Additional information

Weight 1 kg
Dimensions 20 × 20 × 4.5 cm
